REDUCE YOUR CARBON FOOTPRINT WITH AIR-TO-AIR HEAT PUMPS

SPRSUN AIR-TO-AIR HEAT PUMPS

SEARCH FOR SPRSUN AIR SOURCE HEAT PUMPS >>

AIR TO AIR HEAT PUMPS

Air-to-air heat pumps are one of the most efficient electric devices designed for house heating and cooling.
Air-to-air heat pumps help reduce greenhouse gas emissions and improve your comfort.
Air-source heat pumps have lower electricity bills than gas and oil heating systems or geothermal heat pumps.

SPRSUN Air to Water Heat Pump

——

Air Source Monoblock Heat Pumps forHot Water/House Heatin

Advantages of Air to Water Heat Pumps

——

High efficiency

Low carbon heating solutions
Saving on energy costs

Maximizing wall space

Can be installed high up
Maximizing the use of wall space

Heating and cooling available

Winter heating and summer cooling available

What are Air to Water Heat Pumps？

——

Air-to-air heat pumps absorb heat from the outside air and transfer it to the air in your home, raising the air temperature in each room through a series of fan coils.

An air-to-air heat pump can either warm your house in the winter or keep it cool and comfortable in the summer like an air conditioner.
But air-to-air heat pumps cannot provide hot water for your house.
Therefore, you need to consider adding equipment to provide hot water faucets and showers for your home.

Are Air to Water Heat Pump Right for Me？

——

There are many aspects to consider before purchasing air-to-air heat pumps.

First you need to consider the size of the heat pumps and your home. Choosing the right size heat pump according to your house is very important. Too big heat pumps are not energy efficient and expensive in terms of electric bills. Small heat pumps are not good for your heat pumps and will not heat or cool your home properly.

Second, you need to consider the installation site and cost. Make sure you have enough outdoor area to put your heat pump units and allow the warm air to circulate timely. And the installation cost is also one thing you should pay attention to because it will affect your budget.

Lastly, it would be best if you also keep in mind the heat pump efficiency, noise level, cooling and heating capacity, and comfort. These are things that will decide your comfort and room temperature.

Do you have a suitable place to put it?

You need to install the device outside the house. You can hang it on the wall or put it on the floor near the house. You need to make sure you have enough space around the heat pump to realize good ventilation.
How will you heat your rooms?

Most French homes use radiators or under-floor heating to distribute heat to each room. The UK is a little different. While offices may use ducted heating, most homes use boilers to heat the water. Then they move the hot water around the house to heat the radiators. One of the advantages of air-to-air heat pumps is that they do not require a boiler to heat the house.

Air-to-air heat pumps use fan coils/blowers to heat. Blowers are usually installed high in the wall and are suitable for homes with limited wall space. Ducts are commonly used in newer homes because they are often installed in ceiling voids to avoid damage.

Air-to-air heat pumps can have one indoor fan or multiple fans. A heat pump with only one indoor fan is called a single-seal heat pump. A multi-seal heat pump has an outdoor unit and multiple interior fans. In general, single-seal air-to-air heat pumps only heat small homes or rooms. You may need a multi-seal air-to-air heat pump or a ducted system if you have more than two rooms.

You can install an air-to-air single fan system quickly and cheaply. A multi-seal unit requires a pipe from an external heat capture device to each fan. Typically, these pipes run in long plastic tubes at the edges above the room to make them as invisible as possible.
How do you heat your water?

An air-to-air heat pump can cool and heat your room but doesn't provide hot water.

Therefore, you need an alternative unit to heat water for your showers, baths, and faucets.

Choosing the right type of heating depends on how much hot water you need for your home and house space or budget.

You may consider an electric immersion heater, shower, or a "point-of-use" heater. Point-of-use" heaters can heat water with gas, liquefied petroleum gas, or electricity. Gas heaters require a chimney, while you can install your heaters in an inconspicuous spot under the sink.
Can an air-to-air heat pump help me save money?

Whether an air-to-air heat pump will save you money on your energy bills depends on the design and operation of the heat pump and the system you are replacing.

Saving money is not everyone's primary motivation for installing a new heating system, but you need to ensure that installing the system is affordable.

You had better ask your installer for a quote on the heat pump operating costs.
Installation and positioning of blowers/fan coils

The fan coils/blowers are connected to the external unit via ducting.
They are typically installed inside the exterior wall near the outside unit to reduce the interior required duct length.
When planning a multi-fan system, installers often try to minimize the length of ducting to each fan location.
You can ask the installer about possible ducting routes before they begin work.
Installation and positioning of blowers/fan coils

The fan coils/blowers are connected to the external unit via ducting.

They are typically installed inside the exterior wall near the outside unit to reduce the interior required duct length.

When planning a multi-fan system, installers often try to minimize the length of ducting to each fan location.

You can ask the installer about possible ducting routes before they begin work.
Installation of ductwork

Duct systems are often used in very energy-efficient houses. Some types of duct systems are called exhaust air heat pumps (EAHPs). Duct systems may not be well suited for older or larger houses with higher heating needs.

The long, thin duct design allows a large amount of air to move through the house. You can hide these ducts in ceiling gaps. All visible from each room are two grid grilles mounted in the ceiling, one for inflow into the room and one for outflow.

The air is heated in an air handling unit about the size of a boiler, usually installed in the attic or utility room.
Main components of air-to-air heat pump

1. Evaporator

2. Condenser

3. Reversing valve

4. Expansion valve

5. Compressor

6. Piping

7. Fan coils

Air to Water Heat Pump Price

——

The average cost of an air-to-air heat pump for a UK household with two to three people living there is between £1,600 and £3,100.

Installation Price

The costs of installing an air source heat pump can vary from £8,000 to £18,000.

PAC air-to-air	Average price ( with installation)
40 m² Studio	2 000 to 5 000£
80 m²Appartement	3 000 to 6 800£
90m² Maison	3 600 to 7 800£
120m² Maison	4 500 to 8 800£
150m²Maison	5 500 to 11 000£

Type of air-to-air heat pumps	Average price ( with installation)
Mono-split air-to-air heat pump	1 500 to 4 500£
Multi-split air-to-air heat pump	3 000 to 11 000£

Example of air-to-air heat pumps	Average price ( with installation)
5kW multi-split reversible air-to-air heat pump with 2 indoor units	2 800 to 3 200£
3.5 kW mono-split heat pump	1 400 to 1 800£
7kW multi-split air-to-air heat pump with 3 indoor units for a 100m² house	3 800 to 4 600£
14kW reversible heat pump with 8 indoor units	9 600 to 1 0800£

The main parameters that influence your air-to-air heat pump project cost:

Third-party management of domestic hot water
Level of automation
Range of products
The capacity of the heating system
Insulation of the house
Complexity of installation

Running Costs

For every 1 kWh of electricity consumed, an air-to-air heat pump can yield 3 kWh of heat.
In France, most households consume an average of 12,000 kWh of heat annually.

12,000 kWh (heat demand) / 3 kW (heat yielded per 1 kWh of electricity) = 4,000 kWh of electricity
At 4,000 kWh and an electricity price of 0.22 £/kWh, the annual cost of heating is about 880 £.

Financial aid for air-to-air heat pumps

Although air-to-air heat pumps are a modern and efficient way to heat/cool your home, they no longer enjoy substantial financial aid.

What is the cost of a traditional air-to-air heat pump?

Based on your property's size, the average heat pump cost can range from €1,800 to €8,000, with the installation cost included.
What size air-to-air heat pump should I install for a 100m² home?

The output of an air-to-air heat pump ranges from 5500kw to 10500kw, which is suitable for a 100m² home, while the age of the building and the quality of the insulation will also have an impact on this.
How much does an air-to-air heat pump cost?

Depending on the needs, the installation cost of an air-to-air heat pump can range from 500 to 2,000 euros, not including consumable items.

Air to Water Heat Pump Installation

——

How large air-to-air heat pumps do I need?

Air-to-air heat pumps typically range from 5kW to 16kW. The larger your house, the higher the kilowatts you will need.
Typically, a 100 m² property with three bedrooms will require a 7 kW air-to-air heat pump, and a 200 m² house requires a 14 kW air-to-air heat pump.

m²	Home size (in square feet)	Heat pump size (in tons)	Heat pump size (in BTUs)	Power(kW)
46	500	1	12,000	3.5
93	1,000	2	24,000	7
138	1,500	3	36,000	10.5
184	2,000	4	48,000	14

Which side of the house is the best place to install an air source heat pump?

Outdoor heat pump components typically weigh about 120 pounds, so they should always be placed in the shade and avoid direct sunlight.
Place it directly on the side or back of the house, not too close to bushes or vegetation for fear of causing air circulation problems.
Can an electrician install an air source heat pump?

The installation of air source heat pumps is not a simple electrical job as they require qualified and experienced installers for electrical connections and ducting.
Should an air-to-air heat pump be installed away from walls?

When we install a heat pump, we must place it in a place that ensures good air circulation in the unit. If placed parallel to the wall, the minimum distance from the wall is 150 mm. The minimal distance from the front of the heat pump is 1 meter.
Is the installation of an air-to-air heat pump difficult?

The air-to-air heat pump installation is relatively simple for a qualified installer. The ducting and unit layout for a heat pump is no different from a traditional oil or gas furnace, which makes the installation process much simpler.

Air to Water Heat Pump Maintenance

——

Professionals recommend annual inspections of air-to-air heat pumps to ensure efficient operation.

Other than annual inspections, heat pumps rarely require additional maintenance.
You can expect a well-maintained system to run efficiently for at least 20-30 years.

Air to Air VS Air to Water Heat Pumps

——

Air-To-Air VS Air-To-Water Heat Pumps

Air-to-water heat pumps

Air-to-water heat pumps may be the best choice if you need a unit that can heat your radiators. These heat pumps absorb heat from the outside air and transport the heat through pipes to water, then heat your radiators. Even when the temperature drops to -15 degrees Celsius, they can absorb low-temperature heat from the outside air to heat your radiators. As a result, air-to-water heat pumps are very energy-efficient and cost-effective. These heat pumps are up to 350% more efficient than fossil fuel boilers. Therefore, air-to-water heat pumps are a sustainable heating solution to heat your home!

Air-to-air heat pumps

Air-to-air heat pumps can heat and cool your house. These units absorb heat from the outside air. They then use a small amount of electricity to turn the low-temperature, low-pressure refrigerant gas into a high-temperature, high-pressure gas by using a compressor to do the work. The heat energy from the high temperature and high-pressure gas is then released into your home, providing you with heat. Unlike air-to-water heat pumps, which require radiators or underfloor heating, air-to-air heat pumps provide direct heating and cooling.

Compared to air-to-water heat pumps, air-to-air heat pumps are quicker to install because you don't have to make additional changes to your house. Air-to-air heat pumps can even work with your current heating system, giving you more options for temperature control. However, you will still need space for a stand-alone hot water system and an indoor unit.

Which is better?

Like everything has two sides, air-to-water heat pumps and air-to-air heat pumps are no exception. There is no such saying as which is the better choice: both have advantages and disadvantages. We need careful consideration before buying.

The type of heat pump you choose depends largely on your existing heating system and the heating effect you would like to include.

These heat pumps are highly efficient and are a sustainable heating solution, so they may be the best choice when you want to achieve sustainability. Of course, you also need to consider the price and long-term economic benefits, combining all aspects to help you make the best choice.

Ductless vs. Ducted

Benefits of Ductless Heat Pumps

Ductless heat pumps are simpler and easier to install. You need to open a 3-inch hole in the wall to connect the outdoor unit to the indoor unit.

Split ductless heat pump units can achieve higher SEER ratings, up to 25 SEER, resulting in significant cost savings.

A modern ductless air source heat pump consumes only 1 calorie of heat energy but can provide 1.5 to 3 calories. The unit does not produce heat. It only carries heat.

Ductless heat pumps provide consistent indoor temperature control saving you energy and money.

A ductless heat pump keeps less dust in your home because there is no airflow. Filters are added to each air-handling component.

A ductless heat pump, as the name implies, has no ducts, so there is no energy loss through the ducts.

Benefits of Ducted Heat Pumps

Ducted heat pumps' installation is faster.

Ducted heat pump systems take less time and money to maintain. We only need to maintain the outdoor unit and an indoor air handler.

If your house already has ducts, you can install a new heat pump and connect it to the existing ducts.

Ducted heat pump systems allow for more effective humidity control.

Ducted heat pump systems provide more fresh air to your house so you can avoid stagnant air.

With a ducted heat pump system, cool or hot air is passed through the vents, with no need for the indoor units, thus taking up less room space.

Advantages and disadvantages of air-to-air heat pumps

There are no perfect things in the world. Neither are air-to-air heat pumps. I will cover the advantages and disadvantages of air-to-air heat pumps to give you a comprehensive and objective understanding of air-to-air heat pumps.

Advantages of air-to-air heat pumps

Air-to-air heat pumps can perform heating and cooling functions, providing heating in the cold season and cooling in the hot season.
Air-to-air heat pumps do not require the installation of complex heat distribution systems such as radiators or underfloor heating.
The installation cost of air-to-air heat pumps is low and does not require using complex and expensive equipment.
Air-to-air heat pumps have a strong heat transfer capacity. And air-to-air heat pumps are highly efficient, with a seasonal efficiency rating (SCOP) of 3.0-4.0， meaning for every 1 kW of electricity consumed， they can produce 3-4 kW of heat.
The noise level of air-to-air heat pumps is not too loud, generally kept within 60 DB, with the latest air-to-air heat pumps much quieter.
Air-to-air heat pumps are green and do not release harmful substances into the atmosphere.
For any air-to-air heat pump, retrofitting is possible and feasible.

Disadvantages of air-to-air heat pumps

Although there are so many benefits, air-to-air heat pumps also come with some disadvantages of their own.

The COP of air-to-air heat pumps is greatly affected by the outside air temperature. Normally, the lower the temperature, the lower the COP.
At ambient temperature levels as low as -10 degrees Celsius and below, the motor's power consumption increases to ensure proper operation of the heat pump.
Air-to-air heat pumps naturally move the dust in the air as they move the heat in the air.

Is It Worth Installing Air to Air Heat Pump?

——

Air-to-air heat pumps are usually more expensive to install, but you save more money with low maintenance costs throughout the years, making air-to-air heat pumps a great investment. Air-to-air heat pumps are much safer, with no gas leak risks, which can expose you to carbon monoxide. Is it worth installing air-to-air heat pumps?
