R290 Al-Enhanced Inverter Air-Source Swimming Pool Heat Pump

Name: R290 Al-Enhanced Inverter Air-Source Swimming Pool Heat Pump
Brand: SPRSUN
Rating: 5.0 (69 reviews)

The SuperNova R290 AI-Enhanced Inverter Air‑Source Pool Heat Pump combines high efficiency, ultra‑quiet operation and smart control. It delivers up to 26× energy saving with 1kW input producing 26kW heating output. Running at only 37 dB(A), it uses 360° silent technology for peaceful use. AI optimization, IoT remote control, real‑time energy monitoring and OTA update bring convenient operation. With eco‑friendly R290 refrigerant and wide working temperature range, it provides stable, reliable and green heating for all swimming pools.

SKU:
Availability:

Quantity:



Inquire

Model:
CGY025V4-A; CGY030V4-A; CGY035V4-A; CGY040V4-A; CGY050V4-A; CGY060V4-A; CGY-050V4-A; CGY-060V4-A; CGY-070V4-A; CGY-080V4-A
Brand:
SPRSUN

R290 swimming pool heat pump

The SuperNova R290 AI-Enhanced Inverter Air-Source Pool Heat Pump integrates cutting-edge full DC inverter technology and intelligent control systems to deliver exceptional heating performance. With an ultra-high energy efficiency ratio of up to 26 times, 1kW of power input generates 26kW of heating output, significantly reducing energy consumption and operating costs. Equipped with 360° silent technology, it operates as quietly as 37 dB(A) at 1 meter, providing a peaceful pool environment. The advanced AI algorithm optimizes running frequency automatically, while the smart IoT platform enables remote control, real-time energy monitoring and OTA system updates. Adopting eco-friendly R290 refrigerant, this unit features a wide operating temperature range and stable, reliable performance, making it the ideal heating solution for residential and commercial swimming pools.

R290 swimming pool heat pump-smart control

Key Features:

1. Ultra-high Efficiency & Energy Saving

Full DC Inverter technology, up to 26x energy saving
1kW input = 26kW heating output for extremely high efficiency
Smart off-peak thermal storage system to reduce electricity cost

2. Ultra-quiet Operation

Patented 360° silent technology
Sound pressure as low as 37 dB(A) at 1 meter
20x quieter than traditional models

3. AI & Smart IoT Control

AI-optimized compressor frequency for adaptive running
Smart IoT platform for remote control & real-time monitoring
OTA one‑tap system update
Real-time energy consumption display
Smart grid function supports off‑peak preheating

4. Eco-friendly Refrigerant

Adopt R290 natural refrigerant, green and low carbon

5. Stable & Wide Application

Wide operating temperature range
High-efficiency heat exchange with stable performance

R290 swimming pool heat pump-2

SPRSUN R290 DC Inverter Pool Heat Pumps Parameter

Model	CGY025V4-A	CGY030V4-A	CGY035V4-A	CGY040V4-A	CGY050V4-A	CGY060V4-A	CGY-050V4-A	CGY-060V4-A	CGY-070V4-A	CGY-080V4-A
Advised Pool Volume (m³)	25-40	30-60	40-80	45-90	50-100	60-120	50-100	60-120	70-130	80-140
Operating air temperature (℃)	-20°C~43°C
Heating Capacity kW (1)	10	13	17	20	23	27	23	27	32	40
C.O.P Max./Min. (1)	25.61~7.45	25.32~7.41	25.51~7.28	25.22~7.32	25.40~7.05	25.32~7.04	25.40~7.05	25.32~7.04	25.31~7.26	25.30~7.04
COP at 50% capacity	17.2	17.0	17.1	16.9	17.0	17.0	17.0	17.0	17.0	17.0
Heating Capacity kW (2)	7.5	9.75	12.75	15	17.25	20.25	17.25	20.25	24	30
C.O.P Max./Min.(2)	13.31~5.18	13.05~5.15	13.10~5.06	13.03~5.09	13.06~5.05	12.95~5.03	13.05~5.05	12.95~5.03	13.21~5.13	13.11~5.1
Cooling Capacity kW (3)	5.6	7.28	9.52	11.2	12.88	15.12	12.88	15.12	17.92	22.4
E.E.R Max./Min.(3)	5.15~3.37	5.12~3.35	5.03~3.29	5.16~3.4	5.11~3.39	5.08~3.38	5.11~3.39	5.08~3.38	5.12~3.4	5.09~3.35
Noise Level at 1m dB(A)	37~46.6	40~47.9	41.0~48.7	42.2~51.5	43.1~52.3	44.5~53.5	43.1~52.3	44.5~53.5	45.1~54.3	46.5~55.5
Sound pressure at 10m dB(A)	19.8~26.7	19.9~27.9	22.0~28.7	23.2~31.5	24.1~32.3	25.5~33.5	24.1~32.3	25.5~33.5	26.1~34.3	27.5~35.5
Compressor	Panasonic Rotary Compressor
Casing	Galvanized Steel Sheet
Heat exchanger	Titanium Tube in PVC
Power Supply	220–240V~ 50Hz 1N						380–420V~ 50Hz 3N
Rated Input Power(KW)	1.34	1.75	2.34	2.73	3.26	3.84	3.26	3.84	4.41	5.68
Rated Current (A)	5.84	7.63	10.15	11.88	14.18	16.67	6.20	7.28	8.37	10.79
Max Current (A)	8.52	11.14	14.82	17.34	20.71	24.35	9.05	10.63	12.22	15.75
Max Power Input (KW)	1.96	2.56	3.41	3.99	4.76	5.60	4.76	5.60	6.83	8.81
Advised water flux (m³/h)	4.3	5.6	7.3	8.6	9.9	11.6	9.9	11.6	13.8	17.2
Refrigerant	R290
Water pipe in-out size (mm)	φ50
Net Dimension(L×D×H) (mm)	1085465820	1085465820	1085465820	1085465970	1085465970	1085465970	1085465970	1085465970	12605201070	12605201070
Net Weight (kg)	64	88	92	105	124	135	124	130	150	157
Qty per 20'FT / 40'HQ (sets)	44/96	44/96	44/96	44/96	44/96	44/96	44/96	44/96	14/60	14/60
Note: (1) Performance Condition: Air 27℃/Water 26℃/Humidity 80%
(2) Performance Condition: Air 15℃/Water 26℃/Humidity 70%
(3) Performance condition: Air 35℃/Water 28℃/Humidity 64%

The information in this document is just for reference. Since the continuous improvement and control in the production process, the information contained in this document may be subject to change. Please refer to the nameplate on the machine for model specifications.
