SKU: | |
---|---|
Availability: | |
Quantity: | |
CGH02; CGH02-B; CGH03; CGH03-B; CGH06; CGH06-B; CGH-03; CGH-03-B; CGH-06; CGH-06-B; CGH-08; CGH-08-B
SPRSUN
R32 Heat Pump Kit Specification | |||||||
Model | CGH02 | CGH03 | CGH06 | CGH-03 | CGH-06 | CGH-08 | |
Main Configuration | Sheet Metal | Matte gray spray | Matte gray spray | Matte gray spray | Matte gray spray | Matte gray spray | Matte gray spray |
3-Way Valve | DN20 | DN25 | DN25 | DN25 | DN25 | DN25 | |
Filter | Caleffi multifunctional exhaust valve (with micro-bubble exhaust function, impurity filtering function, sewage discharge function, magnet iron scrap absorption function, gas collection function, water pressure display function) | ||||||
Electric Heater | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | |
Water Pump | UPMGEO 25-85 130 | UPMGEO 25-85 130 | UPML GEO 25-105 130 PWM | UPMGEO 25-85 130 | UPML GEO 25-105 130 PWM | UPMXL 25-125 130 PWM | |
Expansion Tank(L) | 5 | 5 | 5 | 5 | 5 | 5 | |
Leakage switch (A) | 32 | 40 | 63 | 25 | 32 | 40 | |
AC Contactor(A) | 18 | 18 | 18 | 18 | 18 | 18 | |
Connection line length (m) | 7 | 7 | 7 | 7 | 7 | 7 | |
Internal and external unit connection cable | 2.5mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 6mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 2.5mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | |
Package | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | |
Parameter | Nozzle size | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) |
Power Supply(V) | 220-240 | 220-240 | 220-240 | 380-420 | 380-420 | 380-420 | |
Max Current(A) | 14.4 | 14.4 | 14.4 | 6.3 | 6.3 | 6.3 | |
Net Weight(kg) | 30 | 36 | 36 | 36 | 36 | 36 | |
Gross weight of carton packaging (kg) | 35 | 41 | 41 | 41 | 41 | 41 | |
Gross weight of plywood packaging (kg) | 45 | 51 | 51 | 51 | 51 | 51 | |
Net Dimension(mm) | 550*285*670 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | |
Packing Dimension(mm) | 645*380*750 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | |
Splint Packaging Dimension(mm) | 640*375*850 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | |
Applicable Models | A101507/A102007 and its extended models | A102507/A103007 and its extended models | A104007/A105007/A106007 and its extended models | A202507/A203007 and its extended models | A204007/A205007/A206007 and its extended models | A208007 and its extended models | |
Model | CGH02-B | CGH03-B | CGH06-B | CGH-03-B | CGH-06-B | CGH-08-B | |
Main Configuration | Sheet Metal | Beige spray | Beige spray | Beige spray | Beige spray | Beige spray | Beige spray |
3-Way Valve | DN20 | DN25 | DN25 | DN25 | DN25 | DN25 | |
Filter | Caleffi multifunctional exhaust valve (with micro-bubble exhaust function, impurity filtering function, sewage discharge function, magnet iron scrap absorption function, gas collection function, water pressure display function) | ||||||
Electric Heater | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | |
Water Pump | Xinhu GPA25-7.5H/130 | Xinhu GPA25-9H/130 | Xinhu GPA25-11 | Xinhu GPA25-9H/130 | Xinhu GPA25-11 | New Territories Pumps APF25-12-130E FPWM1 | |
Expansion Tank(L) | 5 | 5 | 5 | 5 | 5 | 5 | |
Leakage switch (A) | 32 | 40 | 63 | 25 | 32 | 40 | |
AC Contactor(A) | 18 | 18 | 18 | 18 | 18 | 18 | |
Connection line length (m) | 7 | 7 | 7 | 7 | 7 | 7 | |
Internal and external unit connection cable | 2.5mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 6mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 2.5mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | |
Package | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | |
Parameter | Nozzle size | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) |
Power Supply(V) | 220-240 | 220-240 | 220-240 | 380-420 | 380-420 | 380-420 | |
Max Current(A) | 14.4 | 14.4 | 14.4 | 6.3 | 6.3 | 6.3 | |
Net Weight(kg) | 30 | 36 | 36 | 36 | 36 | 37 | |
Gross weight of carton packaging (kg) | 35 | 41 | 41 | 41 | 41 | 42 | |
Gross weight of plywood packaging (kg) | 45 | 51 | 51 | 51 | 51 | 52 | |
Net Dimension(mm) | 550*285*670 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | |
Packing Dimension(mm) | 645*380*750 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | |
Splint Packaging Dimension(mm) | 640*375*850 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | |
Applicable Models | A101508/A102008 and its extended models | A102508/A103008 and its extended models | A104008/A105008/A106008 and its extended models | A202508/A203008 and its extended models | A204008/A205008/A206008 and its extended models | A208008 and its extended models |
R32 Heat Pump Kit Specification | |||||||
Model | CGH02 | CGH03 | CGH06 | CGH-03 | CGH-06 | CGH-08 | |
Main Configuration | Sheet Metal | Matte gray spray | Matte gray spray | Matte gray spray | Matte gray spray | Matte gray spray | Matte gray spray |
3-Way Valve | DN20 | DN25 | DN25 | DN25 | DN25 | DN25 | |
Filter | Caleffi multifunctional exhaust valve (with micro-bubble exhaust function, impurity filtering function, sewage discharge function, magnet iron scrap absorption function, gas collection function, water pressure display function) | ||||||
Electric Heater | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | |
Water Pump | UPMGEO 25-85 130 | UPMGEO 25-85 130 | UPML GEO 25-105 130 PWM | UPMGEO 25-85 130 | UPML GEO 25-105 130 PWM | UPMXL 25-125 130 PWM | |
Expansion Tank(L) | 5 | 5 | 5 | 5 | 5 | 5 | |
Leakage switch (A) | 32 | 40 | 63 | 25 | 32 | 40 | |
AC Contactor(A) | 18 | 18 | 18 | 18 | 18 | 18 | |
Connection line length (m) | 7 | 7 | 7 | 7 | 7 | 7 | |
Internal and external unit connection cable | 2.5mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 6mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 2.5mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | |
Package | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | |
Parameter | Nozzle size | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) |
Power Supply(V) | 220-240 | 220-240 | 220-240 | 380-420 | 380-420 | 380-420 | |
Max Current(A) | 14.4 | 14.4 | 14.4 | 6.3 | 6.3 | 6.3 | |
Net Weight(kg) | 30 | 36 | 36 | 36 | 36 | 36 | |
Gross weight of carton packaging (kg) | 35 | 41 | 41 | 41 | 41 | 41 | |
Gross weight of plywood packaging (kg) | 45 | 51 | 51 | 51 | 51 | 51 | |
Net Dimension(mm) | 550*285*670 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | |
Packing Dimension(mm) | 645*380*750 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | |
Splint Packaging Dimension(mm) | 640*375*850 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | |
Applicable Models | A101507/A102007 and its extended models | A102507/A103007 and its extended models | A104007/A105007/A106007 and its extended models | A202507/A203007 and its extended models | A204007/A205007/A206007 and its extended models | A208007 and its extended models | |
Model | CGH02-B | CGH03-B | CGH06-B | CGH-03-B | CGH-06-B | CGH-08-B | |
Main Configuration | Sheet Metal | Beige spray | Beige spray | Beige spray | Beige spray | Beige spray | Beige spray |
3-Way Valve | DN20 | DN25 | DN25 | DN25 | DN25 | DN25 | |
Filter | Caleffi multifunctional exhaust valve (with micro-bubble exhaust function, impurity filtering function, sewage discharge function, magnet iron scrap absorption function, gas collection function, water pressure display function) | ||||||
Electric Heater | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/220-240~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | ducted 3kW/380-420 2N~ | |
Water Pump | Xinhu GPA25-7.5H/130 | Xinhu GPA25-9H/130 | Xinhu GPA25-11 | Xinhu GPA25-9H/130 | Xinhu GPA25-11 | New Territories Pumps APF25-12-130E FPWM1 | |
Expansion Tank(L) | 5 | 5 | 5 | 5 | 5 | 5 | |
Leakage switch (A) | 32 | 40 | 63 | 25 | 32 | 40 | |
AC Contactor(A) | 18 | 18 | 18 | 18 | 18 | 18 | |
Connection line length (m) | 7 | 7 | 7 | 7 | 7 | 7 | |
Internal and external unit connection cable | 2.5mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 6mm²*3+0.75mm²*5+0.75mm²*2+24AWG*2 | 2.5mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | 4mm²*5+0.75mm²*5+0.75mm²*2+24AWG*2 | |
Package | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | Plywood/Carton | |
Parameter | Nozzle size | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) | DN25(Internal thread) |
Power Supply(V) | 220-240 | 220-240 | 220-240 | 380-420 | 380-420 | 380-420 | |
Max Current(A) | 14.4 | 14.4 | 14.4 | 6.3 | 6.3 | 6.3 | |
Net Weight(kg) | 30 | 36 | 36 | 36 | 36 | 37 | |
Gross weight of carton packaging (kg) | 35 | 41 | 41 | 41 | 41 | 42 | |
Gross weight of plywood packaging (kg) | 45 | 51 | 51 | 51 | 51 | 52 | |
Net Dimension(mm) | 550*285*670 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | 600*290*825 | |
Packing Dimension(mm) | 645*380*750 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | 695*385*905 | |
Splint Packaging Dimension(mm) | 640*375*850 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | 690*380*1005 | |
Applicable Models | A101508/A102008 and its extended models | A102508/A103008 and its extended models | A104008/A105008/A106008 and its extended models | A202508/A203008 and its extended models | A204008/A205008/A206008 and its extended models | A208008 and its extended models |
Our experienced engineering team provides good support for any questions concerning the products and installation before, during and after products are sold.
Before Selling
Set up customers file and arrange professional sales engineers to introduce company products and services to customers in details.
If customers are interested in our products, we will send professional technicians to survey the installation environment.
Provide solutions according to different customers' requirements.
During Selling
Machine installed and tested by QA engineers.
Ensure all the products we provide are qualified and new. The working life of the main engine is 15 years.
Construct and install the heat pump according to national relevant policies strictly and ensure high quality delivery on time.
Test and debug the equipments strictly to ensure the safety and stability.
During the delivery, provide comprehensive and professional technical training on instructions and maintenance to customers.
After Selling
We promise to offer free consulting call in 7×24 hours mode to solve the problems found in practice. The number is 86-20-82181867.
Sprsun offers standard 24-month warranty. Customers can choose to extend the warranty to 5 years with a small amount of fee. Within the warranty period since the delivery date, if the product has any failure under normal usage, Sprsun will provide free assembly parts.
After the expiration of the warranty period, we will continue to provide lifelong maintenance services, with just a small amount of charges.
Our experienced engineering team provides good support for any questions concerning the products and installation before, during and after products are sold.
Before Selling
Set up customers file and arrange professional sales engineers to introduce company products and services to customers in details.
If customers are interested in our products, we will send professional technicians to survey the installation environment.
Provide solutions according to different customers' requirements.
During Selling
Machine installed and tested by QA engineers.
Ensure all the products we provide are qualified and new. The working life of the main engine is 15 years.
Construct and install the heat pump according to national relevant policies strictly and ensure high quality delivery on time.
Test and debug the equipments strictly to ensure the safety and stability.
During the delivery, provide comprehensive and professional technical training on instructions and maintenance to customers.
After Selling
We promise to offer free consulting call in 7×24 hours mode to solve the problems found in practice. The number is 86-20-82181867.
Sprsun offers standard 24-month warranty. Customers can choose to extend the warranty to 5 years with a small amount of fee. Within the warranty period since the delivery date, if the product has any failure under normal usage, Sprsun will provide free assembly parts.
After the expiration of the warranty period, we will continue to provide lifelong maintenance services, with just a small amount of charges.
