Heat Pump Series

R290 Greenergy Series - 25KW Commercial Inverter Heat Pumps

Share to:

R290 Greenergy Series - Light Commercial Inverter Heat Pumps 25KW/30KW

Engineered for sustainable climate control, this light commercial heat pump utilizes eco-friendly R290 refrigerant to provide a versatile 3-in-1 solution: heating, cooling, and domestic hot water. Delivering industry-leading outlet temperatures of up to 75°C, it is a powerful alternative to traditional boilers. Equipped with Smart Inverter Control, the system achieves a COP of up to 5.0 and maintains stable operation in extreme conditions ranging from –25°C to 45°C. It is the definitive energy-saving choice for hotels, resorts, and modern office complexes. This system is not just equipment; it’s a strategic asset for sustainable commercial infrastructure.

SKU:
Availability:

Quantity:



Inquire

Model:
CGK-080V4-B；CGK-100V4-B
Brand:
SPRSUN

Product Details and Parameter

Commercial Air Source Heat Pump_Brochure-6

Model			CGK-080V4-B			CGK-100V4-B
Power Supply		V/Hz/Ph	380-420/50/3			380-420/50/3
Max. Heating Capacity (A7℃/W35℃)		kW	25			30
C.O.P (A7℃/W35℃)		W/W	3.95			3.85
Heating Capacity Min./Max.(A7℃/W35℃)		kW	8.15	/	25.00	10.05	/	30.00
Heating Power Input Min./Max.(A7℃/W35℃)		W	1630	/	6329	2072	/	7792
C.O.P Min./Max.(A7℃/W35℃)		W/W	3.95	/	5.00	3.85	/	4.85
Max. Heating Capacity(A7℃/W45℃)		kW	24.11			28.05
C.O.P (A7℃/W45℃)		W/W	3.42			3.36
Heating Capacity Min./Max.(A7℃/W45℃)		kW	7.42	/	24.11	9.05	/	28.05
Heating power input Min./Max.(A7℃/W45℃)		W	1878	/	7050	2363	/	8348
C.O.P Min./Max.(A7℃/W45℃)		W/W	3.42	/	3.95	3.36	/	3.83
Max. Cooling Capacity(A35℃/W18℃)		kW	20.10			23.90
E.E.R (A35℃/W18℃)		W/W	3.23			3.28
Cooling Capacity Min./Max.(A35℃/W18℃)		kW	8.14	/	20.10	9.29	/	23.90
Cooling Power Input Min./Max.(A35℃/W18℃)		W	2171	/	6223	2497	/	7287
E.E.R Min./Max.(A35℃/W18℃)		W/W	3.23	/	3.75	3.28	/	3.72
Max. Cooling Capacity(A35℃/W7℃)		kW	17.00			19.20
E.E.R(A35℃/W7℃)		W/W	2.56			2.64
Cooling Capacity Min./Max.(A35℃/W7℃)		kW	7.20	/	17.00	8.20	/	19.20
Cooling Power Input Min./Max.(A35℃/W7℃)		W	2087	/	6641	2391	/	7273
E.E.R Min./Max.(A35℃/W7℃)		W/W	2.56	/	3.45	2.64	/	3.43
Max Power Input		kW	11.00			13.50
Max Current		A	16.70			20.50
Wire diameter		mm²	6.0			6.0
Fuse or circuitbreakerer		A	25A			32A
Water Flow		m3/h	4.30			5.16
Hot Water Flow Rate		L/h	518.00			603.00
Compressor Type - Quantity/System		Brand	HIGHLY			HITACHI
Refrigerant / Suggested Input		Kg	R290/1.80			R290/2.1
Fan	Type	/	DC			DC
	Quantity	/	2			2
	Airflow	m3/h	11000			11000
	Rated Fan Speed	RPM	900			900
	Rated power	W	250			250
Water Side Heat Exchanger	Type	/	Plate Heat Exchanger			Plate Heat Exchanger
	Water Pressure Drop	kPa	30			35
	Piping Connection	Inch	G1.2"			G1.2"
Allowable Water Flow	Min./Rated./Max.	L/S	0.75	1.19	1.99	0.90	1.43	2.39
Noise Level (Power Pressure)		dB(A)	63			64
IP Class		/	IPX4			IPX4
Net Dimension(L×D×H)		mm	12495091558			12495091558
Splint packing Dimension(L×D×H)		mm	13405751715			13405751715
Net Weight		kg	220			231
Splint gross Weight		kg	262			/
Pdesignh（35/55℃）		kW	18.373/17.368			22.105/21.090
SCOP（35/55℃）		kWh/kWh	4.73/3.63			4.60/3.47
SCOPon（35/55℃）		kWh/kWh	4.74/3.64			4.61/3.47
QH（35/55℃）		kWh/year	37959/35883			45670/43571
QHE（35/55℃）		kWh/year	8023/9873			9926/12555
Ƞs,h（35/55℃）		--	186.3/142.4			181.0/135.8
Seasonal space heating energyefficiency classes: (According (EU)No 811/2013 Table 2)		--	A+++			A+++
Seasonal space heating energyefficiency classes: (According (EU)No 811/2013 Table 1)		--	A++			A++
Operation Ambint Temp.(℃)		-25~45
Operation water Temp.(℃)		10~70(DHW)
Operation water Temp.(℃)		10~70(Heating)
Operation water Temp.(℃)		12~30(Cooling)
Note: (1) Heating condition: water inlet/outlet temperature: 30℃/35℃, Ambient temperature: DB 7℃/WB 6℃;
(2) Heating condition: water inlet/outlet temperature: 40℃/45℃, Ambient temperature: DB 7℃/WB 6℃;
(3) Cooling condition: water inlet/outlet temperature: 23℃/18℃, Ambient temperature: DB35℃/WB24℃;
(4) Cooling condition: water inlet/outlet temperature: 12℃/7℃, Ambient temperature: DB35℃/WB24℃;

The information in this document is just for reference. Since the continuous improvement and control in the production process, the information contained in this document may be subject to change. Please refer to the nameplate on the machine for model specifications.
